7.1.2.8 Magnetron Current, Running and Transmission Time
This test is used to check the magnetron current by displaying the magnetron current bar.
Procedures
1. Follow procedures 1 to 3 in subsection 7.1.2.1.
The DIAGNOSTIC MENU appears.
The magnetron current bar, the totals of the running and transmission times are
displayed.
RANGE 10kW 25kW
0.125 to 0.75nm 0 to 3 scales 1 to 3 scales
1.5nm 1 to 4 scales 5 to 8 scales
3nm 3 to 5 scales 5 to 8 scales
6 to 96 and 120 nm 4 to 5 scales 5 to 8 scales
Exit
2. Press the
SUB
MENU
key.
The running time indicates the time when the power has been turned on and the transmission time indicates
the total time when transmission has actually been conducted.
Diagnostic Menu
DIAGNOSTIC MENU
Press an item number key.
0. PREVIOUS MENU
1. MEMORY TEST
2. KEY SWITCH TEST
3. SENSOR TEST
4. LINE TEST
5. ROM VERSION
6. ARPA STATUS
7. ERROR LOGGING
8.
9.
MAG. I.
RUNNING TIME 90 HR
TX TIME 55 HR
To close this menu, Press (SUB MENU) key.
