7.5.2 Adjustment and Setting at Installation
7.5.2.1 Adjusting Tuning
Procedures
1. Set the range at 24nm or more to adjust the [TUNE] control at the center.
2. Press the
SUB
MENU
key to open the SUB MENU.
3. Press the
9
key twice to open the INIT SETTING #2 menu.
4. Press the
3
key to select "TUNE ADJUSTMENT".
5. Press the
ENT
key to clear the menu and display the radar screen.
“Adjusting TUNE” will be displayed in the lower right corner of the screen.
6. Press the
RANGE
or
RANGE
key to make the turning indication of the
lower left of the screen the longest and press the
ENT
key.
Init setting #2
INIT SETTING #2
Press an item number key.
0. PREVIOUS MENU
1. BEARING ADJUSTMENT
2. RANGE ADJUSTMENT
3. TUNE ADJUSTMENT
4. SETTING OF PRF 0
5. PM ADJUSTMENT
6.
7. DIAGNOSTIC MENU
8. MAINTENANCE MENU
9. NEXT MENU
To close this menu, Press (SUB MENU) key.
