7 – 5
7.1
7.1.2.5 ROM Version
This test is used to check the versions of the software.
Procedures
1.
Follow procedures 1 to 3 in subsection 7.1.2.1.
The The DIAGNOSTIC MENU appears.
2.
Press the
5
key to open the ROM VERSION.
The versions of the MAIN CPU, NSK, ARPA CPU and ARPA TD are displayed.
Exit
3.
Press the
SUB
MENU
key.
ROM Version
ROM VERSION
0.
PREVIOUS MENU
MAIN CPU
V 1.01
21/09/1998
NSK
V 1.1
ARPA CPU
V 2.2
ARPA TD
V 1.1
To close this menu, Press (SUB MENU) key.
