1 – 1
This equipment is a high performance, high quality, highly reliable and totally-large-scale-integrated
(excluding special electronic tubes) radar composed of a scanner unit, a transceiver and a display unit with
a high resolution color CRT which adopts the raster scan method.
1.1.1 Functions of This Equipment
The major functions include target detecting color display, sea, rain or snow clutter restraint, sensitivity
adjustment, interference rejection, distance and bearing measurement using a trackball, fixed and variable
distance markers and an electronic cursor as well as an optional ARPA (manual and automatic target
acquisition and vector, tracking and warning display), a plotter (own ship tracking and coastal line display)
and an optional simple plotter (make and line display as well as target and course setting).
1.1 Functions
