A – 1
Appendix 1: Radar System Circuit Code List
◎ General code
JMA-3910-4: 10kW, 2-units, 4-feet scanner unit
JMA-3910-6: 10kW, 2 units, 6-feet scanner unit
JMA-3925-6: 25kW, 2 units, 6-feet scanner unit
JMA-3925-7: 25kW, 2 units, 7-feet scanner unit
JMA-3925-9: 25kW, 2 units, 9-feet scanner unit
◎ Scanner unit
NKE-1055 (10kW)
NMA-469A: Modulator
NRG-210A: Receiver
NAX-16A-4/NAX-16A-6: Radiator
CQD-1547: Internal equipment of scanner unit
CQC-931: Internal equipment of Transmitter-receiver unit
CBP-136: Motor
CNM-200: Internal equipment of modulator
CME-261A: Modulator circuit PC201
CMA-662: Internal equipment of receiver
CAE-344-3: IF amplifier circuit PC301
CBP-143: Motor control circuit PC101
CQD-1735: Internal equipment of slow starter
NKE-1056 (25kW)
NMA-470: Modulator
NRG-210A: Receiver
NAX-16A-6/NAX-10-7S/NAX-16A-9:
Radiator
CQC-898: Internal equipment of scanner unit (with diode limiter)
CMH-1562A: Interface circuit PC101
CNM-201: Internal equipment of modulator
CPA-209: Modulator circuit PC210
CMA-662: Internal equipment of receiver
CAE-344-3: IF amplifier circuit PC301
CBP-143: Motor control circuit PC101
CQD-1736: Internal equipment of slow starter
