7.5.7 Adjusting Position to Chart
Adjust the position on the video if it does not correspond to that on the chart in the R+P or plotter (optional)
mode.
7.5.7.1 Adjusting Video and Chart Using Trackball (R+P Mode)
Procedures
1. Press the
SUB
MENU
key to open the SUB MENU.
2. Press the
9
key three times to open the INIT SETTING #3 menu.
3. Press the
1
key to select "SHIFT COAST LINE #1".
4. Press the
1
key to select the "SETTING".
5. Press the
ENT
key to set the system in the adjusting mode.
6. Move the cursor to the position to be adjusted using the trackball and
press the
ENT
key.
7. Move the cursor to another position to be adjusted using the trackball
and press the
ENT
key.
This enables position adjustment.
Cancellation
1. Follow procedures 1 to 4 above to select the "DELETE".
2. Press the
ENT
key.
Position adjustment using the trackball is enabled only in the R+P mode.
INIT SETTING #3
INIT SETTING #3
Press an item number key.
0. PREVIOUS MENU
1. SHIFT COAST LINE #1 SETTING
DELETE
(RADAR PICTURE)
2. SHIFT COAST LINE #2 N 0.000'
E 0.000'
3. LAT ／ LON CORRECTION N 0.000'
E 0.000'
4. CHART CENTER POSITION N 35˚00.000'
E 135˚00.000'
5. DATA INPUT FORMAT
183 JRC 180
6. DATA ／ TIME
OFF UTC LOCAL
7. SHIP'S TYPE FISHING BOAT
MERCHANT
8.
9. NEXT MENU
To close this menu, Press (SUB MENU) key.
