10 – 7
10
(3) Special keys
[For merchant ship]
(1) Floating EBL key: FEBL
(2) Vector + key: VECT+
(3) Vector - key: VECT–
(4) Vector key: VECT
[For fishing ship]
(1) Enlarging/reducing key:
(2) Destination key: DEST
(3) Maker key:
(4) Other ship track key: TRACK
[Switches available when optional equipment is installed]
(1) Starting point key:
(2) End point key:
(3) Target canceling key: CANCEL TARGET
(4) Mark key: MARK
(5) Track key: OWN TRACK
10.5 Inputable Signal
1) Electronic compass
NMEA0183 (HDG, HDT, VHW and HDM) (incompatible with 2-axis log)
2) Navigation system
Equipment capable of outputting NMEA0182/NMEA0183 (GLL, GGA, VTG, RMB and
RMC) or JRC-format signals.
3) Gyro
SYNC/PULSE: 360X, 180X, 90X and 36X
4) Log
SYNCHRO: 360X, 180X, 90X and 36X
PULSE: 800, 400, 200, 100
5) 2-axis log
NMEA0183 (VBW) (incompatible with electronic compass)
6) External event mark
Key input
7) Radar buoy
10.6 Outputable Signal
1) External alarm
2) Sub display unit signal (radar adaptor and operation analyzer)
3) Remote monitor (using vertical multi-scan monitor) (CFQ-8914 connector option)
