10 – 6
10
10
28) Operating positions
(1) By control
(1) Tuning control: TUNE
(2) Snow/rain clutter restraining control: RAIN CLUTTER
(3) Sea clutter restraining control: SEA CLUTTER
(4) Gain adjusting control: GAIN
(5) Brilliance: BRILL
(6) VRM: VRM
(7) EBL: EBL
(8) Power supply: ON/OFF POWER
(2) By switches
(1) Main menu key: MAIN MENU
(2) Sub menu key: SUB MENU
(3) Enter key: ENT
(4) Range expanding key: RANGE △
(5) Range reducing key: RANGE ▽
(6) Panel light key: PANEL DIM
(7) Day/night mode selecting key: DAY/NIGHT
(8) Range scale brilliance key: RANGE RINGS
(9) Bearing mode key: BEARING
(10) Pulse width selecting key: PULSE WIDTH
(11) TM reset key: TM RESET
(12) TM/RM key: TM/RM
(13) Center moving key: OFF CENT
(14) Ship's head marker brilliance key: SHM
(15) Alarm reset key: ACK
(16) VRM control key: VRM
(17) VRM control key OFF
(18) EBL control key: EBL
(19) EBL control key: OFF
(20) Function selecting key: FUNC
(21) Guard alarm key: ALARM
(22) Transmission/standby key: TX/ST-BY
(23) Ten key 0: 0
(24) Ten key 1: 1
(25) Ten key 2: 2
(26) Ten key 3: 3
(27) Ten key 4: 4
(28) Ten key 5: 5
(29) Ten key 6: 6
(30) Ten key 7: 7
(31) Ten key 8: 8
(32) Ten key 9: 9
(33) Clear key: CLR
(34) Reverse key:
(35) Numerical value display key: DATA READ
(36) Acquisition key: ACQ
