2 – 11
In addition to functions to be selected using keys on the front panel, this radar has some other functions
available on menus. To select these functions, press the numeric keys (
0
to
9
),
CLR
and
ENT
keys.
The menu are composed as follows:
MAIN
MENU
[MAIN MENU]
Pressing this key opens the main menu on the bottom of the screen and pressing again clears
it.
SUB
MENU
[SUB MENU]
Pressing this key opens the sub menu on the bottom of the screen and pressing again clears
it.
2.2.1 Menu Selection
(1) In order to select each item on the menu, press the numeric key corresponding to it.
(2) In order to change the contents in the item, press the same key used in (1) to select it and press the
ENT
key.
The underlined setting indicates the current one. The display is highlighted when selected. Pressing the
ENT
key confirms the setting.
(3) In order to change the numerical part in the item, press the same key used in (1), enter an appropriate
value using the numeric key and press the
ENT
. When numeral value input is enabled, the input part
is displayed in a box.
Note
● Press the
CLR
key to clear the input value.
When optional equipment (ARPA, plotter or performance monitor) is not installed, selecting its related
menu is invalid.
2.2 Menu Composition
To Next Page
