3 – 26
3.3
3
When EBL2 is used in the floating mode
EBL2
EBL1
VRM1
VRM2
Displaying VRM
The VRM currently selected is displayed in a box on the lower left
of the screen.
Pressing the [VRM] key once displays (selects) VRM1.
Pressing it again displays (selects) VRM2.
Clearing VRM
Pressing the [OFF] switch once clears the VRM outside a box on
the lower left of the screen.
Pressing it again clears the other VRM.
Bearing Display of VRM
◎ The numerical bearings of VRM1 and VRM2 currently displayed on the PPI is displayed on the lower
left of the screen. Also, VRM1 or VRM2 currently activated is displayed in a box above the range data.
Motion of VRM
◎ Variable range markers are displayed around the own ship. Turn the VRM control clockwise to increase
the scale or counterclockwise to decrease it.
VRM
VRM
OFF
OFF
