3 – 28
3.3
3
To set the radar alarm zone
Procedures
1. Press the
ALARM
key to open RADAR ALARM MENU.
2. Press the
3
key to select "RADAR SECTOR ZONE".
3. Pressing the
ENT
key clears the menu and displays the radar screen.
4. Turn the EBL and VRM controls to set the radar alarm range and press
the
ENT
key.
Use ELB1 to set the originating point of the angle, EBL2 to set the end point of the
angle or VRM1 to set the range.
Note
● The width of the radar alarm range is fixed.
● Do not use the floating EBL for EBL2 being set.
Motion for radar alarm set zone
◎ There are two modes, namely, "IN" mode in which an alarm goes off when a target enters the set circular
radar alarm zone and "OUT" mode in which an alarm goes off when a target goes out of the zone.
◎ The radar alarm set zone is displayed only in the radar transmission mode. Note that it is not displayed
in the standby mode.
To set the alarm mode
Specify whether to output an alarm when a target enters or goes out of the radar alarm set zone.
Procedures
1. Press the
ALARM
key to open RADAR ALARM MENU.
2. Press the
2
key to select "RADAR ALARM MODE".
3. Press the
2
key to select "IN" or "OUT".
4. Press the
ENT
key to confirm the setting.
Exit
5. Press the
ALARM
key.
