3 – 34
3.3
3
To set the cross cursor fixing mode
Procedures
1. Follow procedures 1 to 3 for setting the cursor length to open the CURSOR
menu.
2. Press the
2
key to select "FIXED CURSOR".
3. Press the
2
key to select "X/Y AXES", "X AXIS" or "Y AXIS".
4. Press the
ENT
key to confirm the setting.
Exit
5. Press the
SUB
MENU
key.
Motion of Fixed Cursor
◎ In order to fix the cursor, press the key.
Screen display
Pressing the key once fixes the cursor in the direction of the axis selected
on the menu.
Pressing it again clears the numerical display of the cursor position.
Pressing it again allows the cursor to move freely.
