JRC JMR-5400 Series User Manual

Section 6 Settings 6-24
Radar mode
Save item
Preference to be saved
Default setting or
value after [Default display
configurations]
is clicked on
Location Item
Gain and
anti-clutter
functions
Radar screen
- Radar signal
information
• Receiving sensitivity
adjustment value (Gain)
• Sea clutter adjustment
value (Sea)
• Sea clutter removal
mode
• Rain and snow clutter
adjustment (Rain)
• Rain and snow clutter
removal mode
-
Tuning
Radar screen
- Radar system
information
• Tuning mode
AUTO/MAN
• Fine tuning value (MAN)
• Tuning mode AUTO/MAN:
AUTO
• Fine tuning value (MAN): 0
Range
Radar screen
- Range and mode
information
• Range scale 6 NM
Fixed rings
Radar screen
- Range and mode
information
• Range rings ON/OFF OFF
Operational
alarms
Alert - Collision
Avoidance - AIS Lost
Warning
AIS Lost Warning
• AIS Lost Warning
detection target setting
ON/OFF
TT & Activated AIS
VRMs
Radar screen
- Measuring tools -
EBL/VRM button
area
VRM1 (VRM2)
• Display ON/OFF
• Control right
• Distance value
• EBL1/VRM1
measurement base
point (Empty/C/D and
floating position. C is
saved with the DC
coordinates, and D is
saved with the
coordinates.)
• VRM distance unit
(common to VRM1 and
VRM2)
VRM1:
• Display ON/OFF: ON
• Control right: ON
• Distance value: 0.25 NM
• EBL1/VRM1 measurement
base point: Empty (CCRP)
• EBL2/VRM2 measurement
base point: Empty (CCRP)
VRM2: OFF
• VRM distance unit: NM
EBLs
Radar screen
- Measuring tools -
EBL/VRM button
area
EBL1 (EBL2)
• Display ON/OFF
• Control right
• Bearing value
• EBL bearing
True/Relative (common
to EBL1 and EBL2)
EBL1
• Display ON/OFF: ON
• Control right: ON
• Bearing value: 000.0
EBL2: OFF
• EBL bearing True/Relative:
True
