[In case of the machine without thread trimmer]
1) Install air (asm.)
1
on the bottom face of the table with
two screws
2
supplied with the unit at the position as
shown in the gure.
2) Pull upward knob
3
located at the upper part of the
air (asm.) and turn it to the right or left to adjust the
pressure to approximate 0.5 MPa.
After adjusting the pressure, fully push
down the knob
3
until it comes down to
its home position.
Table
3
2
1
