Juniper SRX Series User Manual

• 8-Port Serial GPIM Key Features on page 99
• 8-Port Serial GPIM LEDs on page 100
• 8-Port Serial GPIM Interface Cables on page 161
• 8-Port Serial GPIM Interface Specifications on page 26
• 8-Port Serial GPIM Basic Configuration on page 230
8-Port Serial GPIM Components
Table 53 on page 98 lists the components of the 8-Port Serial Gigabit-Backplane Physical
Interface Module (GPIM).
Table 53: 8-Port Serial GPIM Components
DescriptionLocationComponent
Use the ONLINE/OFFLINE
button to gracefully shut down
the GPIM. Press down and hold
the button for 4 to 5 seconds
and then release. The GPIM
gracefully shuts down and
turns off the power supply
units (PSUs).
To power up the GPIM (if the
Services and Routing Engine is
off), press and hold the
ONLINE/OFFLINE button for 4
to 5 seconds.
Right side of the GPIMONLINE/OFFLINE button
Only the SRX650 Services
Gateway supports
hot-swappable functionality
for GPIMs. The SRX550
Services Gateway does not
support hot-swappable
functionality for GPIMs.
Two dual stacked 136-pin
VHDCI connectors. Custom
cables are used to connect
from the VHDCI connectors to
the data terminal equipment
(DTE) or the data
circuit-terminating equipment
(DCE)
Middle or right of the GPIMConnector
Use the captive screws to hold
the GPIM in place.
One on each side of the GPIMCaptive screws
Related
Documentation
8-Port Serial GPIM Overview on page 97•
• 8-Port Serial GPIM Hardware Specifications on page 99
• 8-Port Serial GPIM Key Features on page 99
• 8-Port Serial GPIM LEDs on page 100
• 8-Port Serial GPIM Interface Cables on page 161
• 8-Port Serial GPIM Interface Specifications on page 26
Copyright © 2015, Juniper Networks, Inc.98
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
