8-Port Gigabit Ethernet SFP XPIM Basic Configuration
The 8-Port Gigabit Ethernet small form-factor pluggable Gigabit-Backplane Physical
Interface Module (SFP XPIM) provides connectivity to a single Gigabit Ethernet device
or to a network. After you install the XPIM in the services gateway, you configure a network
interface on the XPIM.
NOTE: Only the SRX650 Services Gateway supports hot-swappable
functionality for GPIMs. The SRX550 Services Gateway does not support
hot-swappable functionality for GPIMs.
To configure a network interface on the 8-Port Gigabit Ethernet SFP XPIM :
1. Verify that the 8-Port Gigabit Ethernet SFP XPIM is installed in the services gateway:
user@host >show chassis hardware
The following is a sample output of the command. (The output shown is for an SRX550
Services Gateway; other devices give similar output):
Hardware inventory:
Item Version Part number Serial number Description
Chassis AL1011AA0013 SRX550
Midplane REV 02 750-035027 AADB5084
Routing Engine REV 07 711-035026 AADB5153 RE-SRXSME-SRX550
FPC 0 FPC
PIC 0 6x GE, 4x GE SFP Base
PIC
FPC 3 REV 03 750-037551 AAEC8075 FPC
PIC 0 8x GE SFP gPIM
Xcvr 0 REV 02 740-013111 B302363 SFP-T
Xcvr 1 REV 01 740-011612 9XT702501077 SFP-LH
Xcvr 2 REV 01 740-011612 9XT702501078 SFP-LH
Xcvr 3 REV 01 740-011612 9XT702501079 SFP-LH
Xcvr 4 REV 01 740-011612 9XT702501080 SFP-LH
Xcvr 5 REV 01 740-011620 2850670 SFP-FX
Xcvr 6 REV 01 740-011782 P8Q21GG SFP-SX
Xcvr 7 REV 01 740-020465 5446212 SFP-1000BASE-BX10-D
Power Supply 0 Rev 03 740-024283 VA11443 PS 645W AC
The output shows that FPC 3 PIC 0 is the XPIM.
2. Verify that the PIC on the XPIM is online:
user@host> show chassis fpc pic-status
The following sample output shows that FPC 3 PIC 0 is online:
root@magni02-2a> show chassis fpc pic-status
Slot 0 Online FPC
PIC 0 Online 6x GE, 4x GE SFP Base PIC
Slot 3 Online FPC
PIC 0 Online 8x GE SFP gPIM
3. Verify that the network interface that you want to configure on the XPIM is up:
227Copyright © 2015, Juniper Networks, Inc.
Chapter 26: Configuring Gigabit-Backplane Physical Interface Modules
