1-Port T1/E1 Mini-Physical Interface Module Key Features
The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) provides the following key
features:
•
Channel service unit/data service unit (CSU/DSU) to eliminate the need for a separate
external device
•
56-Kbps and 64-Kbps operating modes
•
Independent internal and external clocking option
•
Alarm reporting with a 24-hour history maintained
•
Loopback, BERT, FDL (T1 only), and Long Buildout (T1 only) diagnostics
•
Multilink Frame Relay and Multilink PPP support
Related
Documentation
1-Port T1/E1 Mini-Physical Interface Module Overview on page 65•
• 1-Port T1/E1 Mini-Physical Interface Module Hardware Specifications on page 66
• 1-Port T1/E1 Mini-Physical Interface Module Network Interface Specifications on page 23
• MTU Default and Maximum Values for Physical Interface Modules on page 12
• 1-Port T1/E1 Mini-Physical Interface Module Supported Standards on page 68
• 1-Port T1/E1 Mini-Physical Interface Module LEDs on page 67
• 1-Port T1/E1 Mini-Physical Interface Module Supported Loopback Diagnostics on page 68
• 1-Port T1/E1 Mini-Physical Interface Module Basic Configuration on page 215
1-Port T1/E1 Mini-Physical Interface Module Hardware Specifications
Table 37 on page 66 gives the physical specifications of the 1-Port T1/E1 Mini-Physical
Interface Module (Mini-PIM).
Table 37: 1-Port T1/E1 Mini-PIM Physical Specifications
ValueDescription
0.80 in. x 3.75 in. x 5.9 in.
(2.0 cm x 9.5 cm x 14.5 cm )
Dimensions (H x W x L)
2.88 oz (82 g)Weight
RJ-48Connector type
Mini-PIMForm factor
32°F through 104°F (0°C through 40°C)Environmental operating temperature
–40°F through 158°F (–40°C through 70°C)Storage temperature
Copyright © 2015, Juniper Networks, Inc.66
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
