CHAPTER 30
Replacing Gigabit-Backplane Physical
Interface Modules
•
Installing a Blank Gigabit-Backplane Physical Interface Module Faceplate on the SRX
Series Services Gateway on page 255
•
Removing a Blank Gigabit-Backplane Physical Interface Module Faceplate from the
SRX Series Services Gateway on page 255
•
Installing a Gigabit-Backplane Physical Interface Module on the SRX Series Services
Gateway on page 256
•
Installing a Double-High, Double-Wide Gigabit-Backplane Physical Interface Module
on the SRX Series Services Gateway on page 258
•
Removing a Gigabit-Backplane Physical Interface Module from the SRX Series Services
Gateway on page 260
Installing a Blank Gigabit-Backplane Physical Interface Module Faceplate on the SRX
Series Services Gateway
To maintain proper airflow through the services gateway, install blank faceplates in slots
that do not contain Gigabit-Backplane Physical Interface Modules (GPIMs).
To install a blank faceplate:
1. Align the captive screws on the blank faceplate with the screw holes on the chassis.
2. Using a Phillips (+) screwdriver, tighten the captive screws on each side of the blank
faceplate until the faceplate is flush with the chassis.
Related
Documentation
Removing a Blank Gigabit-Backplane Physical Interface Module Faceplate from the
SRX Series Services Gateway on page 255
•
Removing a Blank Gigabit-Backplane Physical Interface Module Faceplate from the
SRX Series Services Gateway
To maintain proper airflow through the services gateway, leave blank faceplates in place
over slots that do not contain Gigabit-Backplane Physical Interface Modules (GPIMs).
255Copyright © 2015, Juniper Networks, Inc.
