CHAPTER 15
16-Port Gigabit Ethernet XPIM
•
16-Port Gigabit Ethernet XPIM Overview on page 103
•
16-Port Gigabit Ethernet XPIM Components on page 104
•
16-Port Gigabit Ethernet XPIM Key Features on page 105
•
16-Port Gigabit Ethernet XPIM Hardware Specifications on page 106
•
16-Port Gigabit Ethernet XPIM LEDs on page 106
16-Port Gigabit Ethernet XPIM Overview
The 16-Port Gigabit Ethernet XPIM is a double-high, single-wide LAN switch
Gigabit-Backplane Physical Interface Module (GPIM) that uses two standard slots
vertically. It is available with or without Power over Ethernet (PoE) support. The PoE
GPIMs provide ports that supply electric power over the same ports that are used to
connect network devices. For more information about PoE, see “Power over Ethernet
Support on SRX Series Services Gateway Interfaces” on page 16.
The 16-Port Gigabit Ethernet XPIM must be installed in one of the following 20-Gigabit
slots on the services gateway:
•
SRX550—Slot 3 or 6
NOTE: The 16-Port Gigabit Ethernet XPIM is supported on both slot 3 and
slot 6 of the SRX550 Services Gateway. However, the performance
(bandwidth) in slot 3 will be limited as it has a 10G back link.
•
SRX650—Slot 2 or 6
NOTE: Only the SRX650 Services Gateway supports hot-swappable
functionality for GPIMs. The SRX550 Services Gateway does not support
hot-swappable functionality for GPIMs.
The earliest supported release on the 16-Port Gigabit Ethernet XPIM is Junos OS Release
9.5.
103Copyright © 2015, Juniper Networks, Inc.
