CHAPTER 19
T1/E1 Mini-Physical Interface Module
•
RJ-48 Connector to RJ-48 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 127
•
RJ-48 Connector to RJ-48 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 128
•
RJ-48 Connector to DB-15 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 129
•
RJ-48 Connector to DB-15 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 130
RJ-48 Connector to RJ-48 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module
The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) uses an RJ-48 cable, which
is not supplied with the Mini-PIM.
CAUTION: To maintain agency approvals, use only a properly constructed,
shielded cable.
Table 70 on page 127 gives RJ-48 connector to RJ-48 connector (straight) pinouts.
Table 70: RJ-48 Connector to RJ-48 Connector (Straight) Pinouts
Signal
RJ-48 Pin (Data
Numbering Form)
RJ-48 Pin (on 1-Port
T1/E1 Mini-PIM)
RX, Ring, –11
RX, Tip, +22
TX, Ring, –44
TX, Tip, +55
Shield/Return/Ground33
Shield/Return/Ground66
127Copyright © 2015, Juniper Networks, Inc.
