For advanced configuration information, see the Junos OS Network Interfaces
Configuration Guide.
Using the CLI
To perform basic configuration for the 1-Port Serial Mini-PIM and to configure network
interfaces for the services gateway with the CLI:
•
Verify that the serial interface is installed on the device:
show chassis hardware
•
Verify the status of the interface:
show interfaces terse
•
Assign the port an IP address:
set interfaces se-1/0/0 unit 0 family inet address interface address/destination prefix
•
Add or select a security zone; for example, Trust:
set security zones security-zone trust interfaces se-1/0/0.0 host-inbound-traffic
system-services all
•
Add or select security zones for host inbound traffic protocol options:
set security zones security-zone trust interfaces se-1/0/0.0 host-inbound-traffic protocols
all
•
Set security policies:
set security policies default-policy permit-all
Related
Documentation
1-Port Serial Mini-Physical Interface Module Overview on page 61•
• 1-Port Serial Mini-Physical Interface Module Hardware Specifications on page 62
• 1-Port Serial Mini-Physical Interface Module Supported Standards on page 63
• 1-Port Serial Mini-Physical Interface Module Key Features on page 62
• 1-Port Serial Mini-Physical Interface Module LEDs on page 63
1-Port T1/E1 Mini-Physical Interface Module Basic Configuration
To enable the 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) installed on the
SRX Series Services Gateway, you must configure the basic settings for the PIM. You can
perform the configuration tasks for this using either the J-Web interface or the CLI.
•
Using the J-Web Interface on page 216
•
Using the CLI on page 216
215Copyright © 2015, Juniper Networks, Inc.
Chapter 25: Configuring Mini-Physical Interface Modules
