Table 104: 1-Port G.SHDSL 8-Wire Mini-PIM Data Rates

Data Rates (Mbps)Operating ModesAnnexes

2.3 (maximum)2-wire (4 port 2-wire)Annex A and Annex B

4.6 (maximum)4-wire (2 port 4-wire)

9.2 (maximum)8-wire (1 port 8-wire)

0.768 to 5.6962-wire (4 port 2-wire)Annex F and Annex G

1.536 to 11.3924-wire (2 port 4-wire)

3.072 to 22.7848-wire (1 port 8-wire)

Documentation

• 1-Port G.SHDSL 8-Wire Mini-Physical Interface Module Overview on page 57

• 1-Port G.SHDSL 8-Wire Mini-Physical Interface Module Supported Standards on page 60

• 1-Port G.SHDSL 8-Wire Mini-Physical Interface Module Key Features on page 58

• 1-Port G.SHDSL 8-Wire Mini-Physical Interface Module Hardware Specifications on

page 59

• 1-Port G.SHDSL 8-Wire Mini-Physical Interface Module LEDs on page 59
