Table 81: EIA-530A DCE Cable Pinouts for the 1-Port Serial
Mini-PIM (continued)
Description
LFH-60
PairingDB-25 PinLFH-60 Pin
Data Set Ready (A)-633
Signal Ground-757
Received Line Signal Detector (A)14813
Receive Clock (B)52951
Received Line Signal Detector (B)131014
Terminal Timing (B)5116
Transmit Clock (B)561255
Clear to Send (B)481347
Transmit Data (B)1142
Transmit Clock (A)551556
Receive Data (B)601659
Receive Clock (A)511752
Local Loopback-1845
Request to Send (B)371938
Data Terminal Ready (A)-209
Signal Ground-234
Terminal Timing (A)6245
---26 to 25
---30 to 29
Related
Documentation
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 146
•
• RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 148
145Copyright © 2015, Juniper Networks, Inc.
Chapter 23: Serial Mini-Physical Interface Module Cable Specifications
