Juniper SRX Series User Manual

Related
Documentation
Dual CT1/E1 GPIM Key Features on page 119•
• Dual CT1/E1 GPIM Network Interface Specifications on page 27
• Dual CT1/E1 GPIM Hardware Specifications on page 119
• Dual CT1/E1 GPIM LEDs on page 120
• Dual CT1/E1 GPIM Components on page 118
• Dual CT1/E1 GPIM Basic Configuration on page 235
• Installing a Gigabit-Backplane Physical Interface Module on the SRX Series Services
Gateway on page 256
Dual CT1/E1 GPIM Components
The Dual CT1/E1 Gigabit-Backplane Physical Interface Module (GPIM) contains the
components listed in Table 64 on page 118.
Table 64: Dual CT1/E1 GPIM Components
DescriptionLocationComponent
Use the GPIM ONLINE/OFFLINE button to
gracefully shut down the GPIM.
Right side of the GPIMGPIM
ONLINE/OFFLINE
button
Only the SRX650
Services Gateway
supports
hot-swappable
functionality for
GPIMs. The SRX550
Services Gateway
does not support
hot-swappable
functionality for
GPIMs.
E1 Mode:
•
Transmit bit rate:
2.048 Mbps
•
Receive bit rate:
2.048 Mbps
T1 Mode:
•
Transmit bit rate:
1.544 Mbps
•
Receive bit rate:
1.544 Mbps
Middle of the GPIMTwo fixed T1/E1 ports
labeled 0 and 1
Each port can be
configured using the
CLI in T1 or E1 mode.
Use the captive screws to hold the GPIM in
place in the services gateway.
One on each side of
the GPIM
Captive screws
Related
Documentation
Dual CT1/E1 GPIM Overview on page 117•
• Dual CT1/E1 GPIM Key Features on page 119
• Dual CT1/E1 GPIM Network Interface Specifications on page 27
• Dual CT1/E1 GPIM Hardware Specifications on page 119
Copyright © 2015, Juniper Networks, Inc.118
SRX Series Services Gateways for the Branch Physical Interface Modules Reference
