• RJ-48 Connector to DB-15 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 129
• RJ-48 Connector to DB-15 Connector (Crossover) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 130
• 1-Port T1/E1 Mini-Physical Interface Module Overview on page 65
RJ-48 Connector to DB-15 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module
Table 72 on page 129 gives RJ-48 connector to DB-15 connector (straight) pinouts.
Table 72: RJ-48 Connector to DB-15 Connector (Straight) Pinouts
Signal
DB-15 Pin (Data Numbering
Form)
RJ-48 Pin (on T1/E1
Mini-PIM)
RX/Ring/– <––>RX/Ring/–111
RX/Tip/+ <––>RX/Tip/+32
TX/Ring/– <––>TX/Ring/–94
TX/Tip/+ <––>TX/Tip/+15
Shield/Return/Ground43
Shield/Return/Ground26
No connectNo connect7
No connectNo connect8
No connectNo connect9
No connectNo connect10
No connectNo connect11
No connectNo connect12
No connectNo connect13
No connectNo connect14
No connectNo connect15
Related
Documentation
RJ-48 Connector to RJ-48 Connector (Straight) Pinouts for the 1-Port T1/E1
Mini-Physical Interface Module on page 127
•
129Copyright © 2015, Juniper Networks, Inc.
Chapter 19: T1/E1 Mini-Physical Interface Module
