Juniper SRX Series User Manual

Related
Documentation
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 144
•
• EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 146
• RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 148
• RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 149
• RS-422/449 (EIA-449) DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 150
• RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module on page 152
• V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 155
• X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 157
• X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 158
• 1-Port Serial Mini-Physical Interface Module Overview on page 61
V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
Table 88 on page 155 describes the V.35 DTE cable pinouts.
Table 88: V.35 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
PairingM/34 PinLFH-60 Pin
Frame Ground-A15
Signal Ground-B57
Request to Send-C48
Clear to Send-D37
Data Set Ready-E9
Received Line Signal Detector-F13
Data Terminal Ready-H33
Test Mode-K41
Transmit Data (A)59P60
Receive Data (A)2R1
155Copyright © 2015, Juniper Networks, Inc.
Chapter 23: Serial Mini-Physical Interface Module Cable Specifications
