Table 95: EIA-530 DTE Cable Pinouts for the 8-Port Serial
GPIM (continued)
DescriptionPairingPairDir
DB-25 (2)
Pin
DB-25 (1)
Pin
VHDCI-68
Pin
Receive Data
(B)
T59Pair 2I16T57
Receive Timing
(A)
T54Pair 7I17T56
Local
Loopback
O18T28
Request to
Send (B)
T68Pair 3O19T66
Terminal
Ready (A)
T65Pair 10O20T67
Terminal
Ready (B)
T67Pair 10O23T65
Terminal
Timing (A)
T20Pair 8O24T22
Protocol
Identifier_0
T31 to T27
Protocol
Identifier_2
T53 to T52
Protocol ModeT19 to T18
Related
Documentation
EIA-449 DTE Cable Pinouts for 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 168
•
• EIA-449 DCE Cable Pinouts for 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 163
• EIA-530 DCE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 171
• EIA-530A DTE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 183
• EIA-530A DCE Cable Pinouts for 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 179
• RS-232 DTE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 188
• RS-232 DCE Cable Pinouts for the 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 186
