Table 99: RS-232 DTE Cable Pinouts for the 8-Port Serial
GPIM (continued)
DescriptionDirDB-25 (2) PinDB-25 (1) PinVHDCI-68 Pin
Shield Ground7T51
Receive Ready (A)I8T46
Send Timing (A)I15T7
Receive Timing (A)I17T38
Local LoopbackO18T10
Terminal Ready (A)O20T49
Terminal Timing (A)O24T4
Protocol Identifier_0T13 to T12
Protocol ModeT1 to T3
Shield Ground1T52
Send Data (A)O2T34
Receive Data (A)I3T59
Request to Send (A)O4T68
Clear to Send (A)I5T60
Data Mode (A)I6T63
Shield Ground7T55
Receive Ready (A)I8T64
Send Timing (A)I15T25
Receive Timing (A)I17T56
Local LoopbackO18T28
Terminal Ready (A)O20T67
Terminal Timing (A)O24T22
Protocol Identifier_0T31 to T30
189Copyright © 2015, Juniper Networks, Inc.
Chapter 24: Serial Gigabit-Backplane Physical Interface Module Cable Specifications
