Table 102: X.21 DCE Cable Pinouts for the 8-Port Serial GPIM (continued)
DescriptionPairingPairDir
DB-15 (2)
Pin
DB-15 (1)
Pin
VHDCI-68
Pin
Terminal Timing
(B)
T4Pair 5O13T2
Protocol
Identifier_2
T35 to T33
Shield Ground1T52
Receive Data
(A)
T57Pair 1I2T59
Clear to Send
(A)
T58Pair 2I3T60
Send Data (A)T32Pair 3O4T34
Request to
Send (A)
T66Pair 4O5T68
Terminal Timing
(A)
T20Pair 5O6T22
Shield Ground8T55
Receive Data
(B)
T59Pair 1I9T57
Clear to Send
(B)
T60Pair 2I10T58
Send Data (B)T34Pair 3O11T32
Request to
Send (B)
T68Pair 4O12T66
Terminal Timing
(B)
T22Pair 5O13T20
Protocol
Identifier_2
T53 to T52
Related
Documentation
EIA-449 DTE Cable Pinouts for 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 168
•
• EIA-449 DCE Cable Pinouts for 8-Port Serial Gigabit-Backplane Physical Interface
Module on page 163
Copyright © 2015, Juniper Networks, Inc.198
