D3-DU 3xx/A, /BTechnical data
Project engineering manual V1.09
114
© KEBA 2021
Slave-Feldbus (optional)
Quantity: 1
Ports: 2
Protocol:
Via software configurable:
● EtherCAT
● PROFINET
● EtherNet/IP
EtherCAT:
● Cycle time: 1 - 16 ms
● Sync0/Sync1 period: 1 - 16 ms
FSoE-Slave interface
Watchdog time: 64 - 10.000 ms
FSoE address: 1 - 65,534 (via software configurable)
USB interface
Quantity: 3
Type: USB 2.0 (Hi-Speed)
CFast interfaces
Quantity: 1
Type: Type 1
PCIe interface
Quantity: 1 (only for )
Graphical interface
Quantity: 1
Type: DVI-D (Dual Link)
12.6 (Only for D3-DU 3x5/x) Safe digital inputs (SDI)
Quantity: 20
Type: Type 1 (according to EN 61131-2)
Nominal voltage:
24 V DC PELV, 20 mA, type 1 according to
EN 61131-2
Low-level range: -3 V DC to +5 V DC
High-level range: +15 V DC to +30 V DC
Status display: Green LED
Signal evaluation: Static
Cross-circuiting detection: Yes, via test outputs
OSSD compatible: Yes
Isolation No
