D3-DU 3xx/A, /BDescription of the module

Project engineering manual V1.09

15 ... (Only for D3-DU 3x5/x) 20 Safe digi-

tal inputs (SDI) with corresponding

test outputs (TDO)

16 ... (Only for D3-DU 3x5/x) Status LEDs

of module (MO CMS, STAT)

3.2 Bottom view

Fig.3-2: Bottom side, complete variant

1 ... USB-Port (USB1, USB2) 2 ... DVI-D Graphic interface

3 ... Not connected (at D3-DU 36x/x in-

ternal KEBA interface)

4 ... (Only forD3-DU 3x5/x)(AC and DC)

safe relay outputs (SRO)
