D3-DU 3xx/A, /B Description of the module
Project engineering manual V1.09
23
© KEBA 2021
3.1 Front view
Fig.3-1: Front view, complete variant
1 ... LCD display 2 ... Operating buttons
3 ... Locking of cover flap with operating
panel
4 ... Status LEDs of functional control
(CP, STAT, DISC)
5 ... USB Port (USB 0) 6 ... EtherCAT master interface
7 ... Gigabit ethernet interface 8 ... Master fieldbus (optional)
9 ... Slave fieldbus (optional) 10 ... Slave fieldbus Status LEDs (op-
tional)
11 ... Strain-relief points
A ... Option: D3-DU 3x5/x 12 ... (Only for D3-DU 3x5/x) Status LEDs
of safe relay outputs (SRO)
13 ... (Only for D3-DU 3x5/x) 4 Digital out-
puts
14 ... (Only for D3-DU 3x5/x) 10 Safe digi-
tal outputs (SDO)
