D3-DU 3xx/A, /B Technical data
Project engineering manual V1.09
117
© KEBA 2021
B10
D
when loaded AC1:
3 A at 230 V AC: 1.960.000
1.5 A at 230 V AC: 3.230.000
B10
D
when loaded DC13: 5 A at 24 V DC: 3.230.000
Overvoltage category: III
*)
Category is only valid with corresponding test frequency. See manual
"Functional safety", chapter "KEBA safety control".
Information
A detailed description can be found in the data sheet "SIS 112 5VDC" of
the manufacturer ELESTA.
12.10 (Only for D3-DU 3x5/x) Test digital outputs (TDO)
Quantity: 4
Nominal voltage: 24 V DC PELV
Nominal current: 0.25 A
Short circuit-proof: Yes
12.11 (Only for D3-DU 3x5/x) Digital outputs (DO)
Quantity: 4
Outputtype:
Output (according to EN 61131-2), non stor-
ing
Nominal voltage: 24 V DC PELV
Nominal current: 0.5 A
Status display: Orange LED
Short circuit-proof: Yes
Overload protection: No
Isolation: No
