D3-DU 3xx/A, /BDescription of the module
Project engineering manual V1.09
30
© KEBA 2021
Removing the CFast card
To remove the CFast card, proceed as follows:
1) Turn off the power supply.
Information
Between turning off module supply and removing the CFast card approx.
10 seconds must pass because residual voltage of the device must be
completely released.
2) Open cover (as described in "Inserting the CFast card").
3) First, lightly press the CFast card into the CFast slot until a click is audi-
ble and then remove the released CFast card.
4) Close the cover.
3.7 Accessories
The following accessories can be ordered from KEBA:
Name Description Order no.
Fan
Fan with case (for bottom
fan), only for DU 36x/A-
xxxx-0x
94030
Fan Fan (for top fan) 94656
CR2032 Battery 54080
3.7.1 CFast card
The approved CFast cards may be requested and ordered from KEBA.
Name Description Order no.
D3-XC 340/A CFast card, 2GB 094478
D3-XC 350/A CFast card, 4GB 096878
3.7.2 Connector set
Caution
Only compatible mating connectors that are approved by KEBA must be
used.
The technical data for the terminals are contained in the technical data sheet
of the manufacturer of the female connectors.
The appropriate female connectors are not included in the delivery of KEBA
but can be purchased via KEBA.
