D3-DU 3xx/A, /B Description of the module
Project engineering manual V1.09
25
© KEBA 2021
3.3 Top view
Fig.3-3: Top side (with opened cover)
1 ... Fan 2 ... CFast card slot
The cover on the top side and the cover flap on the front can be opened to
insert storage media or to perform maintenance.
3.4 Type plate
Die Typenschilder unterscheiden sich je nach Variante.
Variant D3-DU 3x0/x
Fig.3-4: Type plate bottom left of the assembly
1 ... Manufacturer 2 ... Manufacturer's address
3 ... Product group 4 ... Product designation
5 ... Technical data functional control
(voltage / current)
6 ... Material / revision number func-
tional control
