- Digital Microscope VHX-5000 User’s Manual -
VHX-5000 Communication Software
14-13
Connecting to an External PC
4 Click [Show Image].
The [Wide view] window and play window opens.
Toolbar
Playing color composition images
1 Select the color composition image file and click
[Playback].
The confirmation message appears.
2 Click [Color Comp Image].
This brings up the playback window and the [Adjust
color comp] dialog box.
3 Adjust each setting while viewing the image.
The following can be adjusted: balance, texture, and
color.
•"Color"
Displays the color image taken with VH lens.
The [Playback in the wide-view window] dialog box
(Page 14-8) appears if the image was recorded at
high definition or a higher size.
Select the image to display in a new window.
Saves the displayed image.
Prints (Page 12-2) the displayed image via the
printer connected to the computer.
Copy the displayed image to the clipboard.
This command is used to measure the image
or add comments.
Allows each item to be readjusted.
Stops HDR playback.
Thumbnails of HDR image files will have a red CL
symbol in the lower right.
To Next Page
