6-36 Keysight B2961A/B2962A User’s Guide, Edition 3
Function Details
Initial Settings
Source mode VOLTS
Source shape DC
Automatic output-on ON
Automatic output-off OFF
Voltage source 0 V
Voltage protection level 2 V
Voltage source auto ranging ON
Voltage source range 2 V
Voltage source range lower limit 0.2 V
Voltage source mode Constant voltage
Voltage sweep points 1
Voltage sweep start 0 V
Voltage sweep stop 0 V
Voltage list points 1
Voltage list values 0 V
Current source 100 A
Current protection level 100 A
Current source auto ranging ON
Current source range 100 A
Current source range lower limit 1 A
Current source mode Constant current
Current sweep points 1
Current sweep start 0 A
Current sweep stop 0 A
Setup item Power on Reset
