Keysight Technologies B2961A User Manual

Keysight B2961A/B2962A User’s Guide, Edition 3 3-21
Installation
Connecting a DUT
Figure 3-6 N1294A-020/021/022 Low Noise Filter


Output
±42V& Max, ± 105 mA Max
N1294A Opt 021
Ultra Low Noise Filter 42 V/105 mA
Push the adapter in firmly until it
locks in-place(< 1mm spacing)
± 42 V & Max
HSHS HF LF LS
Filter

Guard
N1294A Opt 022
Low Noise Filter 210 V/3 A
Push the adapter in firmly until it
locks in-place(< 1mm spacing)
± 250 V & Max
HS HFHS LF LS
Filter
Guard
±210 V
&
Max
High
Sense
High
Force
Low
Sense
Low
Force

Output
±21V& Max, ± 500 mA Max
N1294A Opt 020
HIgh Current Ultra Low Noise Filter
21 V/500 mA
Push the adapter in firmly until it
locks in-place(< 1mm spacing)
± 21 V & Max
HSHS HF LF LS
Guard
Filter

