3 IQ Analyzer (Basic) Mode
3.1 Complex Spectrum Measurement
n Return Value
# Item Unit, if any
12 Averaged delta phase at the averaged FFT trace peak magnitude
frequency
–999 when I/Q Magnitude and Phase Delta Results not available
radians
13 Averaged delta phase at the averaged FFT trace peak magnitude
frequency
–999 when I/Q Magnitude and Phase Delta Results not available
°
14 Current delta magnitude trace in dB
–999 when I/Q Magnitude and Phase Delta Results not available
15 Current delta phase trace in radians
–999 when I/Q Magnitude and Phase Delta Results not available
16 Averaged delta magnitude trace in dB
–999 when I/Q Magnitude and Phase Delta Results not available
17 Averaged delta phase trace in radians
–999 when I/Q Magnitude and Phase Delta Results not available
3.1.1 Views
The Complex Spectrum measurement has only one view ("Normal" on page 146).
3.1.1.1 Normal
Windows:
"Spectrum Window" on
page 147
The upper Spectrum Window shows the trace of the signal and its
average in the frequency domain
"I/Q Waveform" on page
148
The lower I/Q Spectrum Window shows the traces of the I and Q of the
input signal
The figure below shows an example of the view for the Complex Spectrum
Measurement:
IQ Analyzer Mode User's &Programmer's Reference 146
