3 IQ Analyzer (Basic) Mode
3.1 Complex Spectrum Measurement
Meas Preset
Returns the Meas Local variables to their preset values. This is the same as sending
:CONF:SPEC. in the "Complex Spectrum Measurement" on page 143, or
:CONF:STR in the "Streaming Measurement" on page 412.
The only exception is Limits On/Off, which is a persistent Meas Local variable, and is
set to OFF by Mode Preset but not by Meas Preset.
Sample Rate (Remote Command Only)
Returns the sample rate of the current setting.
Remote
Command
[:SENSe]:SPECtrum:SRATe?
Example
:SPEC:SRAT?
Notes Query only
Preset
Mode Value
BASIC 125.0 kHz
BASIC 100 MHz
PNOISE 125.0 kHz
WCDMA 125.0 kHz
LTEA FDD/TDD, 5G NR Automatically calculated
WLAN 31.25 MHz
EDGEGSM 637.5 kHz
MSR 125.0 kHz
Min/Max 12.5 Hz/Option dependent
For Option DP2, B40 or wider IF Bandwidth option:
Digital IF 10 MHz path 12.5 MHz
Digital IF 25 MHz path 31.25 MHz
Digital IF 40 MHz path 50 MHz
Option B85 85 MHz path 106.25 MHz
Option B1A 125 MHz path 156.25 MHz
Option B1X 140 MHz path 175 MHz
Option B1Y 160 MHz path 200 MHz
