7 Save/Recall/Print
7.3 Save
7.3.7.1 Select Correction
Selects the specific Correction to be saved, for example, Correction 1.
Preset Not part of a Preset, but reset to Correction 1 by Restore Input/Output Defaults
Survives a shutdown
7.3.8 SCPI Recorder
Contains controls to allow you to save SCPI recordings.
7.3.8.1 Save To File
Saves SCPI recording content to a file. For details of the SCPI Recording feature, see
"SCPI Recorder" on page 575.
There are two possible file formats:
Type Extension Details
Text
.txt
Default
Python
Script
.py
Generates a Python script that can be executed in Python
environment.. For details, see "Saving a SCPI Recording as a Python
Script" on page 958
The saved file content does not include the label of each recorded entry, just the
SCPI mnemonics. The file is saved to the following folder:
<user_name>:\Documents\Keysight\Infrastructure\ScpiRecording folder
Saving a SCPI Recording as a Python Script
To execute the generated Python script:
–
Install the Python version required by PyVisa
–
Download the PyVisa library from: https://pypi.org/project/PyVISA/
–
Modify the connection string, to specify your instrument’s connection string
Example Script
An example of the generated script is shown below.
# _install location: https://pypi.org/project/PyVISA/
import pyvisa
IQ Analyzer Mode User's &Programmer's Reference 958
