3 IQ Analyzer (Basic) Mode
3.1 Complex Spectrum Measurement
Band Right
Lets you set the right edge frequency for the band of the selected marker.
Remote
Command
Complex Spectrum:
:CALCulate:SPECtrum:MARKer[1]|2|…|12:FUNCtion:BAND:RIGHt <freq>
:CALCulate:SPECtrum:MARKer[1]|2|…|12:FUNCtion:BAND:RIGHt?
Streaming:
:CALCulate:STReaming:MARKer[1]|2|…|12:FUNCtion:BAND:RIGHt <freq>
:CALCulate:STReaming:MARKer[1]|2|…|12:FUNCtion:BAND:RIGHt?
Example
:CALC:SPEC:MARK12:FUNC:BAND:RIGH 20GHz
:CALC:SPEC:MARK12:FUNC:BAND:RIGH?
Couplings Changing Band Right necessarily changes "Band Left" on page 224 and "Band Span" on page 224
Preset 5% of Span
State Saved Yes
Min - Infinity
Max + Infinity
3.1.7.7 Marker To
The controls on this tab let you copy the current marker value into other instrument
parameters (for example, Center Frequency). The currently selected marker is made
the active function on entry to this menu (if the currently selected marker is not on
when you press this front panel key, it is turned on at the center of the screen as a
Normal marker, and then made the active function).
The Marker -> (or Marker To) feature is used to quickly assign a marker’s X- or Y-
Axis value to another parameter. For example, if a marker’s X-Axis value is 500 MHz
and Y-Axis value is –20 dBm, pressing Mkr -> CF assigns 500 MHz to Center
Frequency and pressing Mkr - >Ref Lvl assigns –20 dBm to Ref Level.
All Marker To functions executed from the front panel use the selected marker’s
values, while all Marker To remote commands specify in the command which
marker’s value to use.
Marker Frequency | Time
This is the fundamental control that you use to move a marker around on the trace.
It is the same as "Marker Frequency" on page 204 in Settings.
225 IQ Analyzer Mode User's &Programmer's Reference
