3 IQ Analyzer (Basic) Mode
3.2 IQ Waveform Measurement
Filter Alpha
Sets the filter alpha for the DIF filter. This feature is only available when Option DP2,
B40, or wider IF Bandwidth option is installed.
Remote Command
[:SENSe]:WAVeform:DIF:FILTer:ALPHa <real>
[:SENSe]:WAVeform:DIF:FILTer:ALPHa?
Example
:WAV:DIF:FILT:ALPH 0.5
:WAV:DIF:FILT:ALPH?
Preset 0.2
State Saved Saved in instrument state
Min 0.01
Max 1.00
Backwards Compatibility
SCPI
[:SENSe]:WAVeform:WBIF:FILTer:ALPHa
Channel Filter Bandwidth (Backwards Compatibility Remote Command Only)
Dependencies Only available when Option DP2, B40, or wider IF Bandwidth option is installed
Couplings The value is determined by the following equation
ChannelFilterBwBwcc = (ChannelFilterBw/(DigitalIFBw*OverSampleRatio))
Preset 0.8
State Saved Saved in instrument state
Min 0.01
Max 1.0
Backwards
Compatibility SCPI
[:SENSe]:WAVeform:WBIF:FILTer:BANDwidth <real>
[:SENSe]:WAVeform:WBIF:FILTer:BANDwidth?
3.2.5 Display
Lets you configure display items for the current Mode, Measurement, View, or
Window.
3.2.5.1 View
Contains controls for selecting the current View, and for editing User Views.
IQ Analyzer Mode User's &Programmer's Reference 340
