3 IQ Analyzer (Basic) Mode
3.1 Complex Spectrum Measurement
Band Span
Lets you set the width of the span for the selected marker.
Remote
Command
Complex Spectrum:
:CALCulate:SPECtrum:MARKer[1]|2|…|12:FUNCtion:BAND:SPAN <freq>
:CALCulate:SPECtrum:MARKer[1]|2|…|12:FUNCtion:BAND:SPAN?
Streaming:
:CALCulate:STReaming:MARKer[1]|2|…|12:FUNCtion:BAND:SPAN <freq>
:CALCulate:STReaming:MARKer[1]|2|…|12:FUNCtion:BAND:SPAN?
Example
:CALC:SPEC:MARK12:FUNC:BAND:SPAN 20MHz
:CALC:SPEC:MARK12:FUNC:BAND:SPAN?
Couplings Changing Band Span necessarily changes "Band Left" on page 224 and "Band Right" on page 225
Preset 10% of Span
State Saved Saved in instrument state
Min 0
Max + Infinity
Band Left
Lets you set the left edge frequency for the band of the selected marker.
Remote
Command
Complex Spectrum:
:CALCulate:SPECtrum:MARKer[1]|2|…|12:FUNCtion:BAND:LEFT <freq>
:CALCulate:SPECtrum:MARKer[1]|2|…|12:FUNCtion:BAND:LEFT?
Streaming:
:CALCulate:STReaming:MARKer[1]|2|…|12:FUNCtion:BAND:LEFT <freq>
:CALCulate:STReaming:MARKer[1]|2|…|12:FUNCtion:BAND:LEFT?
Example
:CALC:SPEC:MARK12:FUNC:BAND:LEFT 20GHz
:CALC:SPEC:MARK12:FUNC:BAND:LEFT?
Couplings Changing Band Left necessarily changes "Band Span" on page 224 and "Band Right" on page 225
Preset 5% of Span
State Saved Yes
Min - Infinity
Max + Infinity
IQ Analyzer Mode User's &Programmer's Reference 224
