3 IQ Analyzer (Basic) Mode
3.1 Complex Spectrum Measurement
Auto Function
Remote
Command
Complex Spectrum:
[:SENSe]:SPECtrum:DIF:BANDwidth:AUTO ON | OFF | 1 | 0
[:SENSe]:SPECtrum:DIF:BANDwidth:AUTO?
Streaming:
[:SENSe]:STReaming:DIF:BANDwidth:AUTO ON | OFF | 1 | 0
[:SENSe]:STReaming:DIF:BANDwidth:AUTO?
Example
:SPEC:DIF:BAND:AUTO 0
:SPEC:DIF:BAND:AUTO?
Preset
ON
State Saved Yes
Range Auto | Man
Backwards
Compatibility
SCPI
Not supported in STReaming measurement
[:SENSe]:SPECtrum:BANDwidth:PFFT:AUTO
[:SENSe]:SPECtrum:BWIDth:PFFT:AUTO
[:SENSe]:SPECtrum:BANDwidth|BWIDth:IF:AUTO
Maximum Values
Model Input Option Value
VXT model M9421A RF None 40.0 MHz
B40 40.0 MHz
B85 80.0 MHz
B1X 160.0 MHz
U-B85 Upgrade from 40.0 MHz to 80.0 MHz
U-B1X Upgrade from 80.0 MHz to 160.0 MHz
VXT models
M9410A/11A
RF B40 40.0 MHz
M941xA-B3X 300.0 MHz
M941xA-B6X 600.0 MHz
M941xA-B12 1.2 GHz
M941xAU-B6X Upgrade from 300.0 MHz to 600.0
MHz
M941xAU-B12 Upgrade from 300.0 MHz to 1.2 GHz
M941xAU-BU1 Upgrade from 600.0 MHz to 1.2 GHz
IQ Analyzer Mode User's &Programmer's Reference 236
