3 IQ Analyzer (Basic) Mode
3.2 IQ Waveform Measurement
When B2X/B5X/B1G/B1500M/B2G/B4G paths are available, in Auto mode, the
selections may be disabled if the center frequency of the measurement is not in
range of the minimum/maximum center frequency requirement for these IF Paths.
Depending on the specific hardware, the minimum/maximum center frequency
varies for these IF Paths. In Auto mode, these IF Paths become enabled when the
center frequency of the measurement falls within the valid frequency range
specified for that IF Path. In Auto mode, if the center frequency is not in range, the
application switches into the widest IF Path that can satisfy the center frequency. In
Manual mode, the center frequency is clipped to minimum/maximum value that
specific IF Path allows. A warning message alerts you of the settings conflict.
Remote Command
[:SENSe]:<meas>:IFPath B10M | B25M | B40M | B85M | B125M | B140M | B160M |
B255M | B510M | B1G | B1500M | B2G | B4G | EXT
[:SENSe]:<meas>:IFPath?
[:SENSe]:<meas>:IFPath:AUTO ON | OFF | 1 | 0
[:SENSe]:<meas>:IFPath:AUTO?
For the SPEC and WAVmeasurements in IQ Analyzer (Basic) Mode, omit the <meas> node. For the
VMA Mode Digital Demod measurement, replace the <meas> node with that for the active
measurement; in this case DDEMod
Example IQAnalyzer Mode:
IFP B25M
IFP?
IFP:AUTO ON
VMAMode, DDEMod measurement:
DDEM:IFP B25M
Notes
Option Path
B10M
10 MHz
B25M
25 MHz
B40M
40 MHz
B85M
85 MHz
B125M
125 MHz
B140M
140 MHz
B160M
160 MHz
B255M
255 MHz
B510M
510 MHz
R10
1 GHz
R15
1.5 GHz
R20
2 GHz
