General Programming 6
Keysight M8195A Revision 2 – Arbitrary Waveform Generator User’s Guide 229
Table 37: Segment Id
Bit
Width
Meaning
Data
Idle
31:25
7
Reserved
X
N/A
24:0
25
Segment id (1 .. 16M)
X
N/A
Table 38: Segment start offset
Bit
Width
Meaning
Data
Idle
31:0
32
Allows specifying a segment start address in samples, if only part of a
segment loaded into waveform data memory is to be used. The value
must be a multiple of twice the granularity of the selected waveform
output mode.
X
N/A
Table 39: Segment end offset
Segment End Offset
Bit
Width
Meaning
Data
Idle
31:0
32
Allows specifying a segment end address in samples, if only part of a
segment loaded into waveform data memory is to be used. The value
must obey the granularity of the selected waveform output mode. You
can use the value ffffffff, if the segment end address equals the last
sample in the segment.
X
N/A
Table 40: Command code
Command Code
Bit
Width
Meaning
Data
Idle
31:16
16
Reserved
N/A
X
15:0
16
Command code
0: Idle Delay
N/A
X
Table 41: Idle sample
Idle Sample
Bit
Width
Meaning
Data
Idle
31:8
24
Reserved
N/A
X
7:0
8
Sample to be played during pause. Bits 7:0 contain the DAC value.
N/A
X
