6-10 2G0947 - 31JAN08
Illustrated Parts List
Figure 6-5: FILM FEED AY - Parts List (1 of 3)
Item Part No. Description Qty Notes
1 SP2G0393 HARNESS - cassette 1
2 SP993968 MUFFLER - air 1
3 SP7H2394 FITTING - hose, swivel 1
4 SP2G0463 TUBING - vacuum pump 1
5 SP7E7753 CLAMP - loop, nylon 1
6 SP5F1875 NUT - keps 1
7 SP8F3863 VACUUM PUMP AY 1 M4
8 SP8F4782 TUBING - vacuum pump, T fitting 1
9 SP26-1001-7033-6 TIE WRAP 17
10 SP96-0000-4022-8 FITTING - T, tube to tube 1
11 SP5F4586 E-RING - 6-8 mm 3
12 SP7F2484 PULLEY - 16 groove, 3 mm 1
13 SP7E8486 BELT - timing, 120 tooth 1
14 SP8F4172 CAM - roller set 1
15 SP8F3204 PIN - mounting 1
16 SP8E1025 SENSOR - optical, feed roller nip position 1 S4
17 SP5F8096 SCREW - Torx, M3 0.5x10 2
