2G0947 - 31JAN08 3-35
Adjustments and Replacements
PROCESSOR GASKET
Prerequisites: None
To Remove: NOTE: There are 2 GASKETS, 1 on the HEAT SHIELD and 1 on the INLET
SHIELD.
To remove the GASKET on the HEAT SHIELD:
1. Open the TOP COVER.
2. Release the 2 LATCHES.
3. Remove the HEAT SHIELD.
4. Pull off the old GASKET.
2 LATCHES
HEAT SHIELD
GASKET
HEAT SHIELD
TOP COVER
To Next Page
