3-34 2G0947 - 31JAN08
Adjustments and Replacements
4. Install the new FILM DIVERTER AY and FELT PAD AY, but do not
tighten the 2 SCREWS.
5. Push:
• the FILM DIVERTER AY away from the PROCESSOR DRUM
• the FELT PAD AY against the 2 SCREWS
6. Tighten the 2 SCREWS.
